MEGAL | Bulletproof glass class BR7 "NS"

Name: MEGAL | Bulletproof glass class BR7 "NS"
Brand: MEGAL
Availability: InStock

Manufacturer: MEGAL

Minimum width: 100mm

Minimum height: 100mm

Maximum width: 2250mm

Maximum height: 2000mm

Heat transfer coefficient for glass (W/m2K) - Ug: NPD - No declared heat transfer coefficient value

Glass color: Natural color of building glass

0.00 EUR _{/ m2}

Made to order in the dimensions and quantities specified by the Customer.

MEGAL BR7“NS” bullet-resistant glass is a laminated glazing system which, provides protection against rifle fire, in particular against 7.62 × 51 mm NATO ammunition with a hardened core. It is the highest ballistic protection class specified for bullet-resistant glass under the EN 1063 standard used in construction and is used in facilities of critical security importance. The “NS” (Splinter) designation indicates that no glass fragments are produced on the protected side after impact.

Applications: military and strategic facilities with the highest level of security, embassies, command centres, security checkpoints, VIP protection installations, and critical infrastructure requiring the highest level of ballistic protection.

For every pane of glass we produce, we issue a declaration confirming the product class, supported by testing carried out by international certification bodies. Bullet-resistant glass for special purposes must first and foremost protect human life and property, which is why the precision and quality of our products is confirmed through regular testing.

BR7"NS" bullet-resistant glass is also available in insulating glass units.

Table presenting the classifications and requirements for testing with handguns and rifles in accordance with the PN-EN 1063 standard. The BR7 class of bullet-resistant glass is specified as resistant to fire from 7.62 × 51 mm NATO AP rifle ammunition. The projectile features a hard steel armor-piercing core (“hard core”). The projectile mass and the required firing distance used during testing are also presented. Manufacturer: MEGAL. — The BR7 class is highlighted in the table presenting requirements for testing with handguns and rifles in accordance with EN 1063.

Images are for illustrative purposes only. Visible bullet or impact marks, firearms, and any staging elements are not part of the offered product. The actual appearance of the glass, including its tint, thickness, structure, and level of transparency, may vary depending on technical specifications, display conditions, and the selected configuration of the product.
